Main Material:
1) Exterior structure in colorful steel plate;
2) The edge covered by aluminum alloy.
Technical parameters
|
Appearance |
Color structure of aluminum alloy plate Hemming |
|
Temperature set range |
0—99.9°C |
|
Hatching rate |
≥95% |
|
Temperature measurement accuracy |
±0.1°C |
|
Temperature control accuracy |
≤±0.1°C |
|
Humidity display range |
0—99%RH |
|
Humidity precision control |
±5%RH |
|
Output approach
|
(Medium) 4 (temperature control, left-over eggs, right over the egg, alarm) |
|
(High) 7 Road, (over-temperature, temperature control, low temperature, humidity control, left-over eggs, right over the egg, alarm) |
|
|
Output current |
Temperature Control 220V 10A, the other 200V 1A |
|
Over egg cycle |
0.1--99.9hour(Factory settings 1.5hour) |
|
Eggs over time |
1-255 seconds adjustable (factory set to 180 seconds) |
|
Doubled the number of eggs |
Maximum record 999 times |
|
Ventilation cycle |
5-999 minutes (adjustable, factory 0 hours, non-ventilation) |
|
Ventilation time |
0-999 seconds (adjustable, factory 30 seconds) |
|
Measurement of the line is long |
1.5M |
|
Operating voltage |
AC180V—240V,50/60Hz |
|
Relative humidity |
Less than 85% |
|
Ambient temperature |
-10°C--40°C |
|
Electric power |
200W |
Accessories
Chicken egg incubation technique
|
Total incubation time to hatch, time for transfer to hatcher, and dry and wet bulb temperatures(humidity control) for chicken eggs incubation |
||||||
| Poultry | Incubator Condition | Hatcher Condition | ||||
| Period (Days) |
Dry Bulb (F) |
Wet Bulb (F) |
Transfer at day | Wet Bulb (F) |
Dry Bulb (F) |
|
| Chicken | 21 | 99.5 | 86 | 18 | 98.5 | 90-94 |
Features:
1. High economic benefit: use electricity as the main heat source, coal as the assisstant, including honeycomb briquette,eggette,coal cake,charcoal,liquefied gas,etc. Also it can keep homoiothermal by replacing the hot water;the incubator breed on top, hatcher below .
2. Power on/cut: automatic control with power on; manual supervisory control with power cut.
It can operate after power cut for a certain time;
3, safe and reliable: The stove first heat the water in heater, steam, hot water hose into the water pond,stoves, machines separate, the machine safe without smelly.
The incubator selected high insulation nickel chrome plastic packets to heat.
